| Ø |
l |
dk |
Plage de sertissage |
Diamètre de perçage |
Résistance à la traction |
Résistance au cisaillement |
qtte boite carton |
Cardboard box |
qtte boite plast |
Plastic box |
qtte blister 1 2 |
Blister |
| mm |
mm |
mm |
mm |
mm |
N |
N |
qté |
ref |
qté |
ref |
qté |
ref |
| 3,2 | 6 | 6,5 | 1,0 - 3,0 | 3,4 | 700 | 500 | 500 | 102 132 061 | - | - | - | - |
| 3,2 | 8 | 6,5 | 3,0 - 5,0 | 3,4 | 700 | 500 | 500 | 102 132 081 | - | - | - | - |
| 3,2 | 10 | 6,5 | 5,0 - 7,0 | 3,4 | 700 | 500 | 500 | 102 132 101 | - | - | - | - |
| 3,2 | 12 | 6,5 | 7,0 - 9,0 | 3,4 | 700 | 500 | 500 | 102 132 121 | - | - | - | - |
| 3,2 | 14 | 6,5 | 9,0 - 11,0 | 3,4 | 700 | 500 | 500 | 102 132 141 | - | - | - | - |
| 3,2 | 16 | 6,5 | 11,0 - 13,0 | 3,4 | 700 | 500 | 500 | 102 132 161 | - | - | - | - |
| 4,0 | 6 | 8,0 | 0,5 - 2,0 | 4,2 | 1200 | 800 | 500 | 102 140 061 | - | - | - | - |
| 4,0 | 8 | 8,0 | 2,0 - 4,0 | 4,2 | 1200 | 800 | 500 | 102 140 081 | - | - | - | - |
| 4,0 | 10 | 8,0 | 4,0 - 6,0 | 4,2 | 1200 | 800 | 500 | 102 140 101 | - | - | - | - |
| 4,0 | 12 | 8,0 | 6,0 - 8,0 | 4,2 | 1200 | 800 | 500 | 102 140 121 | - | - | - | - |
| 4,0 | 14 | 8,0 | 8,0 - 10,0 | 4,2 | 1200 | 800 | 500 | 102 140 141 | - | - | - | - |
| 4,0 | 16 | 8,0 | 10,0 - 12,0 | 4,2 | 1200 | 800 | 500 | 102 140 161 | - | - | - | - |
| 4,0 | 18 | 8,0 | 12,0 - 14,0 | 4,2 | 1200 | 800 | 500 | 102 140 181 | - | - | - | - |
| 4,0 | 20 | 8,0 | 14,0 - 16,0 | 4,2 | 1200 | 800 | 500 | 102 140 201 | - | - | - | - |
| 4,8 | 8 | 9,5 | 1,0 - 3,0 | 5,0 | 2000 | 1300 | 500 | 102 148 081 | - | - | - | - |
| 4,8 | 10 | 9,5 | 3,0 - 5,0 | 5,0 | 2000 | 1300 | 500 | 102 148 101 | - | - | - | - |
| 4,8 | 12 | 9,5 | 5,0 - 7,0 | 5,0 | 2000 | 1300 | 500 | 102 148 121 | - | - | - | - |
| 4,8 | 14 | 9,5 | 7,0 - 9,0 | 5,0 | 2000 | 1300 | 500 | 102 148 141 | - | - | - | - |
| 4,8 | 16 | 9,5 | 9,0 - 11,0 | 5,0 | 2000 | 1300 | 500 | 102 148 161 | - | - | - | - |
| 4,8 | 18 | 9,5 | 11,0 - 13,0 | 5,0 | 2000 | 1300 | 500 | 102 148 181 | - | - | - | - |
| 4,8 | 20 | 9,5 | 13,0 - 15,0 | 5,0 | 2000 | 1300 | 500 | 102 148 201 | - | - | - | - |
| 4,8 | 25 | 9,5 | 15,0 - 20,0 | 5,0 | 2000 | 1300 | 250 | 102 148 251 | - | - | - | - |
| 4,8 | 30 | 9,5 | 20,0 - 25,0 | 5,0 | 2000 | 1300 | 250 | 102 148 301 | - | - | - | - |
TA reduced head - TA Coloured rivets - Other sizes
- Grip Range
- Drilling Diameter
- Tensile Strength
- Shear Strength
